HUB MOUNT TRACKS

DOUBLE YOUR CAPABILITY AND PRODUCTIVITY

Let us help you achieve more with Vimcor Hub Mount Tracks. When the conditions get wet and your in need of tracks, the Vimcor hub mount tracks adapt to your existing equipment for greater flotation and reduced compaction. Use them for your air seeder during planting, then simply transfer them to your chaser bin during harvest for double the value.

DISCOVER THE BENEFIT OF HUB MOUNT TRACKS

With a focus on strength Vimcor Hub Mount Tracks are designed to be the strongest and most durable tracks in its class. Australian designed and built, the tracks have an impressive handling capability of up to 35t and purpose designed for smooth maneuverability, eliminating the shuttering that can occur when transporting implements.

With basic tooling at hand and use of a forklift, the hub mount tracks can be transferred in half an hour from one implement to another - taken into consideration that the equipment has a standard 10 or 12 stud hub and appropriate clearance. Your Vimcor Hub Mount Tracks will distribute weight more evenly, reducing compaction leading to greater flotation and improved water infiltration.

DESIGNED AND PURPOSE BUILT TRACKS

  • Strong reinforced frame design with a handling capacity of 30t or 35t depending on model
  • Shallow belt pattern and a ground contact of more than 2.275m significantly increases flotation, reduces soil compaction with minimal berming.
  • Constant track tension is easily maintained by an inbuilt hydraulic accumulator system with an easy to check pressure gauge and pressure release system.
  • Reduced Maintenance with heavy duty wheel hubs

SPECIFICATIONS FOR STANDARD UNDERCARRIAGE

Model

Capacity (per set)

Track Width

Tread

Weight




 Height  Ground Contact Length Track Footprint Total Track Centres Mid Wheel Diameter Idler Wheel Diameter
35T-HM-V1
35 tonne 24" or 36" 1505mm 2275mm
 4.16m² (36")  n/a  400mm  1475mm  4480kg
30T-HM-V1
30 tonne 24" or 36" 1505mm 2275mm
 4.16m² (36")  n/a  400mm  1475mm  4480kg

TRACK COMPATIBILITY

Click on the image to enlarge

HUB MOUNT TRACK OVERVIEW
